2-4 Operating the Monitor
Part Number 255636-001 - - Writer: Troy Witte - Saved by Troy Witte
Saved date: 09/23/97 2:15 PM - File Name T:\docs\codename\partnumber\CH2.DOC
The following tables list the second level menus and their functions.
Size and Position Functions
Control Icon Function
Horizontal-
Size
Increases or decreases horizontal width
of the screen.
Horizontal-
Position
Moves screen horizontally left or right.
Vertical-Size
Increases or decreases vertical width of
the screen.
Vertical-
Position
Moves screen vertically upwards or downwards.
Cancel Cancels the adjustment.
Save and Return Saves adjustment and exits to main menu.
Geometry Functions
Control Icon Function
Pincushion Adjusts the left and right margins for more
convex or more concave margins.
Tilt Adjusts the screen’s image rotation or tilt adjust.
Trapezoid Adjusts the trapezoid of the screen by moving
the lines inward or outward.
Cancel Cancels the adjustment.
Save and Return Saves adjustment and exits to main menu.
Degauss Function
Control Function
Degauss Corrects color impurity caused by external
magnetic fields.
Confirm Reset
Control Function
Reset
Resets the monitor screen to the default or the
factory settings.
Cancel Cancels the settings reset.
To Next Page
