Comparc DELTA MIG 455 - Operation Sequence

10
Breathing welding fumes can be hazardous to your health.
1.- Cylinder.
2.- Cylinder valve.
3.- Gun torch trigger.
Before welding open cylinder valve, to activate the trigger
the arc welding is started.
Finishing welding shut the cylinder valve.
3
2
1
Figure 4-8. Gas supply.
CAUTION
4-8 OPERATION SEQUENCE FOR GMAW, FCAW, SAW AND CAC-A.
Install and
connect the
equipment
Turn On Wire feeder
and Power Source
Put On
safety
equipment
Install and
prepare Flux
system
Install and
prepare
wire feeder
Set Control
Turn On Flux
system
Beging welding
Figure 4-11 Submerged arc process (SAW)
Readjsut
controls and
begin welding
Open
gas
valve
Turn On Wire
feeder and Power
Source
Put On
safety
equipment
Install and
prepare
wire feeder
Install and
connect the
equipment
Figure 4-10 Flux cored arc welding process (FCAW).
Figure 4-9 Solid wire process (GMAW).
Readjsut
controls and
begin welding
Put On
safety
equipment
Install and
prepare
wire feeder
Install and
connect the
equipment
Turn On Wire
feeder and Power
Source
Set Controls
Put On
safety
equipment.
Select
coat
electrode
Connect
compreser air
system
Inssert electrode into
torch
Supply
compresed air
Turn On Power
Source
Start cutting or
gouging
Install and
connect the
equipment
Figure 4-12 Air cutting and gouging process (CAC-A).
