3-3 INSTALLING SUPPORT FOR MIG GUN.
1.- Remove two screws (1/4" x 1/2" ) in cover (2) and side deckl (3) as shown in figure.
2.- Place the support on the cover (1) and beside deck (2) as shown in figure.
3.- Ensure the support (1) with screws (1/4" x 1") (4).
Tools needed:
- 3/8"
To place the support for MIG gun on welding power source, follow instructions bellow.
2
3
4
1
4
