KMS F4h KMS active flag

Reserved for keyboard F5h – F6h Reserved 2 bytes for keyboard used

Unused F7h – FEh Unused

Assettag number 200h – 23Fh

64 bytes for DMI Type 3

LAN MAC Address 240h –

245h

6 bytes for LAN without EEPROM

Unused 246h –

25Fh

Unused

ACPI OEM ID 260h – 265h 6 bytes for ACPI OEM ID

Unused 266h –

26Fh

Unused

ACPI OEM Table ID 270h – 277h 8 bytes for ACPI OEM Table ID

Reserved 278h - 7FFh

Reserved

4.10.5 OEM Active 1.0/2.0/2.1/3.0 and KMS activation Support

OEM Activation 1.0 (a.k.a. SLP 1.0) is used to activate Windows XP. To support it,

BIOS needs to populate OEM string in the 0xF000 segment during POST.

OEM Activation 2.0 (a.k.a. SLP 2.0) is used to activate Windows Vista. To support it,

BIOS needs to populate ACPI SLIC table during POST.

For projects supports Windows 7, SLP 2.1 is required to support.

For projects supports Windows 8, OA 3.0 is required to support.

MS claims the Windows marker is MS’s IP and cannot appear on non-Windows OS

SKUs. An EEPROM flag OS_SKU (refer Sec. 4.10.4) is defined to indicate the

machine is shipped with Windows or non-Windows OS. The flag is programmed in

the factory and BIOS needs to read this flag when populating OEM string/ACPI SLIC

table. If the flag indicates the machine is shipped with non-Windows OS, BIOS will

not load Windows marker structure in ACPI SLIC table.

KMS Activation support.

To support the KMS activation, the SLIC table should be removed from the ACPI

table.

To support multi customer, BIOS should remove the SLIC table as default, and

populate the SLIC table if customer enter the OEM ID, OEM table ID and OS_SKU in

the EEPROM. The customer should create customized BIOS with SLP2.0/2.1

market and public key at the same time to active Vista/Window 7. Please refer to the

“How to update OEM SLP” for the detail instruction of customized BIOS creation.
