Error checking will be done against month/day/year combinations that

are not supported.) INCREASE/REDUCE:+/-.

4.11.3 Advanced

InsydeH20 Setup Utility

Main Advanced Security Boot Exit

Num lock <Off>

Details see the following

Help Information

Configure SATA as <AHCI>

USB Legacy <Enabled>

F1 Help ↑↓Select Item F5/F6 Change Values F9 Setup Defaults

Esc Exit

← → Select Menu

Enter Select 4SubMenu

F10 Save and Exit

Numlock

Enter this menu, you can choose the ON or Off in this submenu. This function just

works under DOS. In OS number lock is controlled by EC.

Configuration SATA as

Choose HDD mode through selecting the IDE mode or AHCI mode.

Note: Intel SharkBay Ult (LPT-LP) platform does not support legacy IDE mode or

combination mode.

USB Legacy

You can select the Disabled or Enabled in this menu according to the owner

requests;

Help information:

Num Lock

Selects Power-on state for Num lock.

Configure SATA As
