20
PERFORMANCE SPECIFICATIONS
Power Source 3.7V Battery
Number of Output Modes 6 preset modes
Timer Range (minutes) 20-50
Dimensions (mm) [L x W x D] 66 x 56 x 18 mm
Waveform Biphasic
Shape Rectangular
Maximum Output Voltage 72V@500Ω
Maximum Output Current 144mA@500Ω
Maximum Pulse Duration 345µSec
Maximum Frequency 184Hz
ELECTRODE MAINTENANCE
The electrodes are disposable. Electrodes have a shelf life of 2 years, are intended for single person
use, and should be replaced as necessary. If the electrode no longer contacts well with your skin, it
is time to replace it. If needed, you can use a damp and clean cloth to wipe electrodes between uses.
Electrodes can be ordered at
www.compex.com
