VI. DESCRIPTION
Parts
A LCD display
B “On/Off” switch ( )
C “+”/”–” keys of the
4 stimulation channels
D Four sockets for the
4 electrode cables
E Electrode cables
channel 1 = blue
channel 2 = green
channel 3 = yellow
channel 4 = red
F Socket for the battery
charger
G Compartment for the
rechargeable battery
Figure 1 (Topside)
Figure 2 (Underside)
B
D
A
C
E
F
G
