16 Version 1.2
Main components
К1, K2, К3, К4 Contactor YA Solenoid valve
М1 Electric motor R Electronic controller
Т Temperature sensor I/P Pressure sensor
SB Emergency stop TN1, TN2 Overload relay
F1, F2 Fuses TR Transformer
МКС Phase sequence relay QS Automatic power switch
2.7 Electrical connection values
Voltage (V) Frequency (Hz) A07.. A11.. A15.. A18.. A22..
Cable size (mm²)
400 50 2,5/4 4/6 6/10 10/16 10/16
380 50 2,5/4 4/6 10/10 10/16 16/16
Fuse value (A)
380-400 50 35 35 50 63 63
Motor overload relay (A)
380-400 50 15,5 12,7 16,7 20,2 23,7
3. Start up
3.1 Lifting and carrying
All lifting should be carried out using a forklift truck with a carrying
capacity suited to the compressor.
Lifting may be carried out with loading cranes, winches and other
machinery, using a crossbeam with the right length.
Local safety guidelines for lifting have to be observed.
For transport with a forklift truck, use the rigging holes in the frame.
The compressor has slotted rigging holes with width C – g. 3.1.
Move the compressor carefully.
