Comprag A1808 - Dimensions

18 Version 1.2
С
G
A
Fig. 3.2 Lifting and carrying AR07..-AR22, ARD07..-ARD22
Model
Compressor dimensions Packaging dimensions
Length
L, mm
Width D,
mm
Height H,
mm
Weight ,
kg
Length
L, mm
Width D,
mm
Height H,
mm
Weight ,
kg
А07 750
700
985 260 850 800 1195 270
А11
900 1170
293
1100 800 1330
365
А15 315 383
А18
1000 800 1270
415
1200 900 1500
457
А22 435 486
L
D
H
Fig. 3.3 Dimension drawing A07.. – A22..
3.2 Dimensions
