Hardware specifications
Processor / SoC
Type
Intel Apollo Lake (Atom | Celeron | Pentium)
Dual-core or quad-core
Memory
Supported
1x SO-DIMM 204-pin DDR3L SDRAM
Up to 16GB Non-ECC DDR3L-1866 (1.35V)
Storage
Supported
1x M.2 M-key 2242 | 2260
Optional eMMC
Optional 2.5” HDD | SSD
Graphics
Display Interface 1
HDMI 1.4b up to 3840 x 2160 @ 30Hz
Display Interface 2
DisplayPort 1.2 up to 4096 x 2160 @ 60 Hz (via Mini DP connector)
Audio
Codec
Realtek ALC1150 HD audio codec
Audio Output
Analog stereo output | Digital 7.1 channels S/PDIF output (3.5mm jack)
Audio Input
Analog stereo Microphone input (3.5mm jack)
Networking
LAN
LAN1: Intel I211 GbE controller (RJ-45)
LAN2: Intel I211 GbE controller (RJ-45)
Wireless
1x M.2 E-key 2230 slot
WiFi adapter sold separately
Connectivity
USB
2x USB 3.0
2x USB 2.0
Serial
1x Serial communication ports
COM1: RS232 via mini serial connector
Expansion
FACET rev 2 slot (PCIe x2, USB2.0, eDP1.3, I2S, I2C, UART)
Operating System
Supported
Windows 10 | Linux
Operating Conditions
Input Voltage
Unregulated 7 - 20VDC input
Power Consumption
5W to 15W
depending on configuration and system load
Operating Temperature
Commercial: 0°C to 45°C
Extended: -20°C to 70°C
Industrial: -40°C to 85°C
Relative Humidity
5% to 95% (non-condensing)
Enclosure
Material
Die Cast Aluminum
Cooling
Passive Cooling (fanless)
Dimensions
112 mm X 84 mm X 34 mm
Weight
350g
Warranty
5 years
Warranty notes
Storage device warranty in accordance with device manufacturer’s warranty.
Excludes battery.
For the latest specifications please visit:
www.fit-iot.com/web/products/fitlet2/fitlet2-specifications/
