12-6
DTMF Programming Commands (Transceiver)
ENTRY DESCRIPTION DEFAULT
*27 READ WEATHER STATION DATA SETTING
*30XX SEND VOICE MESSAGE (01-12)
*31XX PROGRAM VOICE MESSAGE (01-12)
*32XX ERASE VOICE MESSAGE (01-12)
*501* PROGRAM CONTROL OPERATOR PREFIX 100
*503* PROGRAM DTMF PAD TEST PREFIX 375
*504* PROGRAM WEATHER REPORT PREFIX 200
*505* PROGRAM VOICE DEMOSTRATION PREFIX 700
*610* PROGRAM DTMF INTERDIGIT TIMER (0.1 – 9.9 SECONDS) 1.0
*91 SEND AUDIO TEST TONE (REPEATER)
*92 SEND AUDIO TEST TONE (LINK)
*93 SEND AUDIO TEST TONE (REPEATER + LINK)
*0 MANUAL EXIT OF PROGRAMMING MODE
Figure 12-3
DTMF Inter-Digit Timer [*610*]
This timer determines the time between entries of DTMF digits that make-up a command. This timer is
programmable between 0.1 and 9.9 seconds. The timer default is 1 second. When the CAT-200B is
unlocked and placed in the programming mode, the DTMF inter-digit timer doubles in length. This
provides more time to enter the programming commands. Once the CAT-200B is locked with the [*0]
command this timer returns to the normal setting.
