Computer Automation CAT-200B User Manual

2-1
Chapter 2 - System Configuration
Repeater With Fixed Frequency Transceiver
In this configuration the CAT-200B supports a repeater with a CTCSS decoder and a transceiver on a
fixed frequency.
CAT-200B
CAT-200B REPEATER AND TRANSCEIVER CONFIGURATION
J3-6
J3-4
J3-25
J3-10
J3-11
J3-13
J3-1
COR #1
CTCSS #1
PTT #1
TX AUDIO #1
RX AUDIO #1
GROUND
USER INPUT #3
USER INPUT #4
USER INPUT #1
USER INPUT #2
J3-22
J3-21
J3-2
J3-15
J3-14
USER OUTPUT #3
USER OUTPUT #2
USER OUTPUT #1
J3-19
J3-20 USER OUTPUT #4
J3-17
J3-16
GROUND
+12VDC OUTPUT
J3-5
J3-23
J3-9
J3-3
COR #2
TX AUDIO #2
PTT #2
CTCSS #2
RX AUDIO #2J3-12
J3-8 FAN CONTROL
GROUNDJ3-18
REPEATER
TRANSCEIVER
J3-7 CTCSS ENCODER
Figure 2-1
