Conair GB - Specifications; One Conair Drive Pittsburgh, PA

One Conair Drive ● Pittsburgh, PA 15202 ● 412-312-6000 ● FAX 412-312-6227 ● www.conairnet.com
MODELS GBM22 GBM31 GBM40
Performance characteristics
Batch size lbs {g} .882 {400} .882 {400} .882 {400}
Maximum throughput lbs/hr
{kg/hr}* 97 {44} 111 {50} 132 {60}
Bin capacity - large bins ft
3
{liter}
0.4 {11.3} 0.4 {11.3} 0.4 {11.3}
Maximum number of materials 4 4 4
Number of standard dispensing valves
†
234
Number of micro dispensing valves 2 1 0
Control software (# of components) 4 or 12 4 or 12 4 or 12
Dimensions inches {mm}
A - Height above mounting plate 27.25 {693} 27.25 {693} 27.25 {693}
B - Width 21.75 {552.4} 21.75 {552.4} 21.75 {552.4}
C - Depth 21.75 {552.4} 21.75 {552.4} 21.75 {552.4}
D - Controller height 11.25 {285.75} 11.25 {285.75} 11.25 {285.75}
E - Controller width 12.25 {311.15} 12.25 {311.15} 12.25 {311.15}
F - Controller depth 8.19 {208.03} 8.19 {208.03} 8.19 {208.03}
Weight lbs {kg}
Installed 70 {32} 70 {32} 70 {32}
Shipping 90 {41} 90 {41} 90 {41}
Voltage Running load amps
120V/1 phase 50/60 hz 1.0 1.0 1.0
220V/1 phase 50/60 hz 0.5 0.5 0.5
Compressed air requirements
40 psi @ 1 ft
3
/min { 2.8 bars @ 0.47 liters/sec}
1/4 in. NPT fitting
Material filling options
Self-contained vacuum loader ML8 or Z2HL
Central vacuum receiver DL8
Hand-fill flat lid
GRAVIMETRIC BATCH BLENDERS
Autoweigh GBM Series Models
MOUNTING INTERFACE
SPECIFICATION NOTES:
* Maximum throughput rates are based on
using all dispense valves and dispensing no
more than 1.0% colorant and/or additive per
each micropulsing valve. Refer to the selec-
tion guide for more specific throughput infor-
mation.
† The Regrind position features a 1.5-inch
diameter valve to ensure flow or irregularly
shaped material.
If you will be using this blender for central
blending applications, it will be necessary to
use a flow control valve with an air solenoid.
SPECIFICATIONS
TPBS015/0700
CONTROL (REMOTE MOUNTED)
