14 - Your ConceptD notebook tour
Right view
USB 3.2 Gen 2 information
• USB 3.2 Gen 2 compatible ports are blue.
• Compatible with USB 3.2 Gen 2 and earlier devices.
• For optimal performance, use USB 3.2 Gen 2-certified devices.
• Defined by the USB 3.2 Gen 2 specification (SuperSpeed USB).
# Icon Item Description
1
External display
(DisplayPort)
port
Connects to a display device using
the high-definition DisplayPort
interface.
2 HDMI port
Supports high-definition digital video
connections.
3 USB port Connects to USB devices.
4
Ethernet (RJ-45)
port
Connects to an Ethernet 10/100/1000-
based network.
Pull the lip down to open the port fully.
5 DC-in jack Connects to an AC adapter.
6
Ventilation and
cooling fan
Allows the computer to stay cool.
Do not cover or obstruct the
openings.
7 Active stylus Draws, writes or highlights the text.
