Conceptronic C54BRS4A User Manual
65
Operating Voltage
5VDC +/- 10%
Radio and Modulation Type
For 802.11g:
OFDM:
BPSK @ 6 and 9Mbps
QPSK @ 12 and 18Mbps
16QAM @ 24 and 36Mbps
64QAM @ 48 and 54Mbps
DSSS:
DBPSK @ 1Mbps
DQPSK @ 2Mbps
CCK @ 5.5 and 11Mbps
For 802.11b:
DSSS:
DBPSK @ 1Mbps
DQPSK @ 2Mbps
CCK @ 5.5 and 11Mbps
Wireless Transmit Power
Typical RF Output Power at each Data Rate
For 802.11g:
31mW (15dBm) @ 54 and 108Mbps
40mW (16dBm) @ 48Mbps
63mW (18dBm) @ 36, 24, 18, 12, 9, and 6Mbps
For 802.11b:
63mW (18dBm) @ 11, 5.5, 2, and 1Mbps
Receiver Sensitivity
For 802.11g:
1Mbps: -94dBm
2Mbps: -91dBm
5.5Mbps: -89dBm
6Mbps: -91dBm
9Mbps: -90dBm
11Mbps: -86dBm
12Mbps: -89dBm
18Mbps: -87dBm
24Mbps: -84dBm
36Mbps: -80dBm
54Mbps: -73dBm
For 802.11b:
1Mbps: -94dBm
2Mbps: -90dBm
5.5Mbps: -88dBm
11Mbps: -85dBm
