Consul 2.35 - Technical Details for Specific Lift Models

OPERATING & INSTALLATION INSTRUCTION 2-POST-LIFT
Technical details H300 / H301 / H327 / H339 / H331 / H354 / H355
Type: H300 EL-
S
H300 EL-A H300 EL-C
H339 EL-
RMC
H301 EL-S H327 EL-S H354
Prolift 2.30
EL
H355
Prolift 2.40
EL
H331 EL-S
Remark:
with
symmetric
swivel arms
with asymmetric
swivel arms
with sill lifting
version
with symmetric
swivel arms
with symmetric
swivel arms
with asymmetric
swivel arms
with symmetric
swivel arms
with symmetric
swivel arms
Width (mm): 3.300 3.100 3.300 3.300 3.200 3100 3200 3500-3850
Height
(mm)ca.:
2540 2540 2540 2540 2560 2540 2560 2920
Max. vehicle
width (mm):
2.460 2.260 2.460 2.460 2.560 2260 2700 2380-2730
stroke
(mm):
1.900 1.900 1.900 1.900 1.900 1900 1900 1750
Lifting height
(mm):
1995 1990 1980 2005 2005 1990 1995 1905
min. arm
clearance
(mm):
95 90 Drive on-
Heigh:
70
95 85 70 85 115
Lifting time
(sec):
47 47 47 47 47 47 47 40
Net weight
(kg):
620 620 650 700 700 620 700 1000
Load capacity
(kg):
*
3.000 3.000 3.000 3.500 4000 3000 4000 6000
Motor power
(kW):
2x3 2x3 2x3 2x3 2x3 2x3 2x3 2x3
Voltage(V): 400 400 400 400 400 400 400 400
ED-
power:
S3 S3 S3 S3 S3 S3 S3 S3
Current (A): 16 16 16 16 16 16 16 16
Fuse rating (A
gl):
20 20 20 20 20 20 20 20
Noise level
(dB(A)):
78 78 78 78 78 78 78 78
Subject to change without prior notice !
* The load distribution should not exceed the ratio 3:2 !!!
