OPERATING & INSTALLATION INSTRUCTION 2-POST-LIFT
If the lift is set up by the operator himself, the attached assembly and operating instructions must
be observed. Subsequently the lift must be subjected to safety acceptance by a Consul customer
service section. This includes the following performances:
 Electrical functional check and trial run.
 according to BGG 945
 examination of the individual structural components.
 Entry in the check list.
 Short instruction.
-If these points are not observed, the guarantee expires.-
7. Annual expert check (UVV)
In addition to the check prior to the initial commissioning of the lift by our customer service section,
the official regulations demand at least one safety acceptance per year experts. Our customer
service section will be pleased to submit you a quotation for a maintenance contract.
8. Assembly cost rates and invoicing
The performances of the customer service section stated are invoiced in accordance with the
respectively applicable terms and conditions of assembly, hourly rates and lump-sum travelling
amounts. Securing material is not included in the scope of delivery of the lifts.
9. Guarantee
On the basis of the fact that lifts must satisfy hight safety requirements for the protection of the
persons working on them, we draw your attention to the fact that we must tie the guarantee
entitlement of the operator to the correctly performed safety acceptance and entry of this in the
check list. Always uses original spare parts. The use of any other parts invalidates the design
permit and all claims under warranty.
Service memorandum standard fundaments
Individual fundaments: Concrete floor
(hall floor)
Type: Fundament dimensions Fundament characteristics
Length in
direction of travel
Width in
direction of
travel
Min, thickness
without floor
covering
Quality of
concrete
Anchoring
depth
dowels
*
Consul 2.25 RMC 150 cm 350 cm 15 cm B25 11 cm
Consul 2.30 Modula 120 cm 100 cm 21 cm B 25 13 cm
Consul 2.30 Modula EL 120 cm 100 cm 21 cm B 25 11 cm
Consul 2.35 Modula 120 cm 100 cm 21 cm B 25 13 cm
Consul 2.35 Modula EL 120 cm 100 cm 21 cm B 25 11 cm
Consul 2.40 Modula EL 120 cm 100 cm 21 cm B 25 13 cm
Consul 2.60 2M 150 cm 350 cm 21 cm B 25 10 cm
Consul 2.60 2M GF/EL 150 cm 150 cm 21 cm B 25 10 cm
Prolift 3003 GA 120 cm 100 cm 18 cm B 25 13 cm
Prolift 2.30 EL 120 cm 100 cm 21 cm B 25 11 cm
Prolift 2.40 EL 120 cm 100 cm 21 cm B 25 13 cm
The setting up of the lifts is only admissible and will only be carried out if the minimum requirement on the
fundaments indicated are fulfilled at the place of setting up.
see page 6 * in the respect the information of the dowel manufacturers is binding!
subject to change without prior notice!
Page 5
