OPERATING & INSTALLATION INSTRUCTION 2-POST-LIFT
Technical details H264 / H265 / H342 / H325
Type: H264-S H264-A H264-C
H265-S H342 - S H325
Remark: with symmetric
swivel arms
with asymmetric
swivel arms
with sill lifting
version
with symmetric
swivel arms
with symmetric
swivel arms
with symmetric
swivel arms
Width (mm): 3400 3050 3400 3.300 3250
3000
Height (mm)ca.: 2565 2565 2565 2540 2880 2615
Max. vehicle
width (mm):
2440 2440 2440 2.460 2380 2350
Stroke
(mm):
1.900 1.900 1.900 1.900 1750 1900
Lifting height
(mm):
2000 1985 2000 2005 1925
1990
min. arm
clearance (mm):
98 85 Drive-on-high:
80
95 115 90
Lifting time
(sec):
47 47 47 47 45 45
Net weight (kg): 620 620 650 700 700 650
Load capacity
(kg):
*
3.000 3.000 3.000 3.500
6000
3000
Motor power
(kW):
3 3 3 3 3 3
Voltage (V): 400 400 400 400 400
400
ED-
power:
S3 S3 S3 S3 S3 S3
Current (A): 16 16 16 16 16 16
Fuse rating (A
gl):
20 20 20 20 20 20
Noise level
(dB(A)):
78 78 78 78 78 78
Subject to change without prior notice!
The load distribution should not exceed the ratio3:2!
