OPERATING & INSTALLATION INSTRUCTION 2-POST-LIFT
Adjustment for synchronisation 34987.8 (3to)
38096.4 3,5 and 4to
Slider
spring
Nut
and
bolt
If necessary, adjust the pre-tension
of the spring by means of the nut!
-
+
The lift has an adjustable brake on both columns. This stops the weight
of the vehicle causing the columns to lower at different
speeds. The tension on the springs can be adjusted to synchronise
the lifting carriages.
Subject to change without prior notice!
When the hood has been removed and the system is load-free, it
should just be possible – using both hands – to turn the large
belt disc.
