OPERATING & INSTALLATION INSTRUCTION 2-POST-LIFT
Attention!
Important instructions for assembling the 2-Post-Lift!
1. The assembly should be carried out by qualified staff in accordance with the construction and operating
instructions (otherwise the guarantee will be invalidated).
2. Check that all parts have been delivered before commencing assembly.
3. Final insulation checks must be carried out according to VDE instruction 0100.
4. Test instructions are to be complied with, in accordance with BGG945.
5. Instructions for the foundations of the lift must be strictly observed.
6. Carefully ensure that the drive shaft is parallel to the spindle shaft when assembling the lift. To adjust
this the two flat head screws can be loosened, then retightened.
7. Check the locking mechanism of the swivel arm, then ensure that the bolt is vertical and parallel to the
front of the column.
8. Only ever fill the automatic lubrication system with original Consul Spindle Oil.
9. The lift is preprogrammed in the factory and must be adjusted to local conditions. Check that the foot
protection facility is at the correct height (compulsory stop and signal tone).
10. Be aware of the alignment (outward lean) of the columns.
11. Check the gap between the steering frame and the tension band (correst and grease the back of the
tension band when necessary).
12. The self-securing swivel arm screws only reach complete tightness after 24 hours (check for a gap of 1
to 2 mm between the screw head and the swivel arm bearing)
13. Check the adjustment of the chain break switch on lifts with chain synchronization.
14. After the first test run without a load, a test run with a nominal load must be carried out.
15. Observe maintenance schedule (swivel arms, spindles, bearings of turntable).
16. Only lift using all 4 swinging arms and only at the lifting points permitted by the manufacturer.
Consul Werkstattausrüstung GmbH
Daimlerstr. 1
D-58553 Halver
Telefon: ++49 (0)2353-7009-0
Telefax: ++49 (0)2353-12515
E-Mail: info@consul-gmbh.de
