Continental Fireplaces BCDV36PTR - Minimum Mantel Clearances

39
W415-0802 / C / 12.15.10
BRICK
COMBUSTIBLE NON-COMBUSTIBLE
2”
1”
0” IF
NON-COMBUSTIBLE
FINISHING IS USED
SUCH AS BRICK
AND STONE.
24” MINIMUM
PLUS RISE*
2”
39”
6” MINIMUM
BRICK
COMBUSTIBLE NON-COMBUSTIBLE
2”
1”
0” IF
NON-COMBUSTIBLE
FINISHING IS USED
SUCH AS BRICK
AND STONE.
2”
42
3
/8” MINIMUM
PLUS RISE*
48
3
/8”
2” MINIMUM
16”
1
1
/2”
TOP EXIT ENCLOSURE
The appliance requires a minimum enclosure height
of 48 3/8". For temperature requirements, the
enclosure space around and above the appliance
must be left unobstructed.
REAR EXIT ENCLOSURE
The appliance requires a minimum enclosure height
of 39". For temperature requirements, the enclosure
space around and above the appliance must be left
unobstructed.
* See "VENTING" section.
6.3.2 BCDV36
Combustible Mantel clearance can vary according to the Mantel depth. Use the graph
to help evaluate the clearance needed. These same requirements apply to any
combustibles protruding on either side of the appliance.
TOP OF
APPLIANCE
8" MANTEL
8"
6"
6"
4"
4"
2"
2"
M
A
N
T
E
L
H
E
I
G
H
T
0
2
4
6
8
10
12
24681012
MANTEL DEPTH
6.4 MINIMUM MANTEL CLEARANCES
!
WARNING
RISK OF FIRE, MAINTAIN ALL SPECIFIED AIR SPACE CLEARANCES TO COMBUSTIBLES. FAILURE
TO COMPLY WITH THESE INSTRUCTIONS MAY CAUSE A FIRE OR CAUSE THE APPLIANCE TO
OVERHEAT. ENSURE ALL CLEARANCES (I.E. BACK, SIDE, TOP, VENT, MANTEL, FRONT, ETC.) ARE
CLEARLY MAINTAINED.
WHEN USING PAINT OR LACQUER TO FINISH THE MANTEL, THE PAINT OR LACQUER MUST BE
HEAT RESISTANT TO PREVENT DISCOLOURATION.
