2
W415-0780 / D / 08.13.12
NOTE: Changes, other than editorial, are denoted by a vertical line in the margin.
TABLE OF CONTENTS
1.0 INSTALLATION OVERVIEW 3
2.0 INTRODUCTION 4
2.1 DIMENSIONS 5
2.2 GENERAL INSTRUCTIONS 5
2.3 GENERAL INFORMATION 6
2.4 RATING PLATE INFORMATION 7
3.0 VENTING 7
3.1 VENTING LENGTHS AND COMPONENTS 8
3.2 TYPICAL VENT INSTALLATIONS 9
3.3 SPECIAL VENT INSTALLATIONS 10
3.3.1 PERISCOPE TERMINATION 10
3.4 VENT TERMINAL CLEARANCES 11
3.5 VENT APPLICATION FLOW CHART 12
3.6 DEFINITIONS 12
3.7 ELBOW VENT LENGTH VALUES 12
3.8 HORIZONTAL TERMINATION 13
3.9 VERTICAL TERMINATION 15
4.0 INSTALLATION 17
4.1 WALL AND CEILING PROTECTION 17
4.2 HORIZONTAL INSTALLATION 18
4.3 VERTICAL INSTALLATION 19
4.4 USING FLEXIBLE VENT COMPONENTS 19
4.4.1 HORIZONTAL AIR TERMINAL INSTALLATION 20
4.4.2 VERTICAL AIR TERMINAL INSTALLATION 21
4.4.3 APPLIANCE VENT CONNECTION 21
4.5 VERTICAL THROUGH EXISTING CHIMNEY 22
4.6 MOBILE HOME 23
4.7 GAS INSTALLATION 23
4.8 OPTIONAL WALL SWITCH INSTALLATION 24
5.0 FRAMING 24
5.1 MINIMUM CLEARANCE TO COMBUSTIBLES 26
5.2 INSTALLING STANDOFFS 27
5.3 MINIMUM ENCLOSURE CLEARANCES 27
5.4 ALCOVE FRAMING 28
5.5 MINIMUM MANTEL CLEARANCES 29
6.0 FINISHING 30
6.1 DOOR INSTALLATION / REMOVAL 30
6.2 REMOVING THE VALVE ACCESS DOOR 30
6.3 DOOR TRIM 31
6.4 GRATE INSTALLATION 31
6.5 LOG PLACEMENT 31
6.6 GLOWING EMBERS 32
6.7 CHARCOAL EMBERS 32
6.8 VERMICULITE 32
6.9 CHARCOAL LUMPS 32
6.10 LOGO PLACEMENT 32
7.0 OPTIONAL BLOWER INSTALLATION 33
7.1 ACCESSING THE BLOWER 33
7.2 INSTALLING THE BLOWER 34
8.0 OPERATION 35
9.0 ADJUSTMENTS 36
9.1 PILOT BURNER ADJUSTMENT 36
9.2 VENTURI ADJUSTMENT 36
9.3 FLAME CHARACTERISTICS 37
9.4 RESTRICTING VERTICAL VENTS 37
10.0 MAINTENANCE 38
10.1 CARE OF GLASS 38
10.2 GLASS / DOOR REPLACEMENT 39
11.0 REPLACEMENTS 40
12.0 TROUBLESHOOTING 43
13.0 WARRANTY 46
14.0 SERVICE HISTORY 47
