Drive
Assembly
Collar
Rotation pot
15
3B6
Loosen
the top side set screws on
the collar
Use a 1.5mm
allen
wrench.
Swing the boom,
centered
directly over the
rear of the
Machine.
Location
is inside turret
Calibration
Rotation
Sensor
14
16
Table of Contents
Table of Contents
4
System Layout
5
System Components
6
SLIM Display
6
Cable Reel Set-Up
9
System Password
10
Calibration Min Angle/Length
12
Calibration Max Angle/Length
13
Calibration Save
14
Calibration Rotation
15
Wiring Diagram
18
