UD53 User Guide
Issue code: 53nu3
13
Pulses per revolution
The maximum number of pulses per revolution (PPR) of the simulated-
encoder outputs depends on the resolution of the SIN and COS inputs; the
resolution is affected by the maximum speed which is set in 1.06 and/or
1.07), as follows:
Maximum speed
[1.06]
Resolution of
the
SIN and COS
inputs
Maximum pulses per revolution of
the simulated-encoder outputs
RPM Quadrature
Frequency and
direction
0 ~ 3000 14-bit 4096
8192
3001 ~ 12000 12-bit 1024
4096
12000 10-bit 256
1024
The actual PPR is dependent on the resolution of the SIN and COS inputs as
well as on the value of 16.07 Simulated-encoder output scaling.
If a different
PPR is required, enter the required scaling value in parameter
16.07 Simulated-encoder output scaling. The scaling factor is given by the
following:
1
2
16 07[.]
