Control Techniques UD53 User Manual

UD53 User Guide
Issue code: 53nu3
8
4.2 Functions of the terminals
Terminal Function
40 Simulated-encoder
phase quadrature output A
or frequency output F
(EIA485 serial link)
41 Simulated-encoder
phase quadrature output A\
or frequency output F\
(EIA485 serial link)
42 0V
43 Simulated-encoder
phase quadrature output B
or frequency output D
(EIA485 serial link)
44 Simulated-encoder
phase quadrature output B\
or frequency output D\
(EIA485 serial link)
45 0V
46 Marker pulse Z output
47 Marker pulse Z \ output
48 SIN coil input (low)
49 SIN coil input (high)
50 COS coil input (low)
51 COS coil input (high)
52 Excitation output (high)
53 Excitation output (low)
54 0V
55 0V
