Control Techniques UD53 User Manual

UD53 User Guide
Issue code: 53nu3
9
Resolver UD53
(high)
(low)
(high)
(low)
(high)
(low)
SIN
COS
Excitation
Resolver
SIN
COS
Excitation
Figure 3 Resolver connections to the UD53
