UD53 User Guide
Issue code: 53nu3
3 Installing the UD53
Warning
Before using the following procedure, refer to the
Warnings at the beginning of Chapter 2 Installing the Drive in
the Unidrive Installation Guide.
1 Before installing the UD53 in the Unidrive, ensure the AC supply has
been disconnected from the Drive for at least 10 minutes.
2 Check that the exterior of the UD53 is not damaged, and that the
multi-way connector is free from dirt and debris. Do not install a
damaged or dirty UD53 in the Drive.
3 Remove the terminal cover from the Drive (for removal instructions,
see Installing the Drive and RFI filter in Chapter 2 of the Unidrive
Installation Guide).
4 Position the multi-way connector on the rear of the UD53 over the
connector in the Drive (see Figure 1), and press on the thumb pad to
push the UD53 into place.
5 Re-fit the terminal cover to the Drive.
6 Connect the AC supply to the Drive.
7 Set parameter .00 at 149 to unlock security.
8 Check that parameter 16.01 is set at 3 to indicate that the module is
fitted.
9 If the check in step 8 fails, perform the following:
• Remove the
AC supply from the Drive.
• Wait at least 10 minutes.
• Remove the terminal cover.
• Check that the UD53 is fully inserted.
• Replace the terminal cover.
• Re-apply the
AC supply.
• Check again that parameter 16.01 is set at
3.
