140 Unidrive User Guide
www.controltechniques.com Issue Number: 9
Figure 10-9 Menu 5 Closed-loop vector logic diagram
4.04
Current
demand
4.12
Current demand
filter time constant
Filter
+
4.13
4.14
Current loop
P gain
Current loop
I gain
5.10
5.11
Motor rated
power factor
Motor number
of poles
5.02
Motor
voltage
5.03
Total mot o r
power (kW)
√ 3 x V x I
5.18
5.19
PWM
switching
frequency
High stability
space vector
modulation
Volt
Hertz
L1 L2 L3
5.05
DC Bus
voltage
_
Current controller
5.09
Motor rated
voltage
5.07
5.08
Motor rated
current
Motor rated
full load RPM
5.06
Motor rated
frequency
5.29
5.30
Motor saturation
breakpoint 1
Motor saturation
breakpoint 2
5.28
Field weakening
gain compensation
disable
5.24
5.26
Motor leakage
inductance
Cross coupling
compensation
enable
5.21
Field gain
reduction enable
5.31
5.32
Voltage controller
gain
Motor full load
speed fine trim
5.20
5.33
Quasi square
wave enable
Thermal
model
protection
4.02
Motor active
current
4.02
4.20
4.17
4.01
Motor
current
magnitude
Motor magnetising
current
Motor active
current
Percentage
active current
5.27
Slip autotune
Motormap
5.12
Autotune
0.XX
0.XX
Key
Read-write (RW)
parameter
Read-only (RO)
parameter
Input
terminals
Output
terminals
The parameters are all shown at their default settings
