Parameter
Range(
Ú) Default(Ö)
Type
OL CL OL VT SV
8.01 Digital input/output F1
state 0 or 1 RO Bit P
8.02 Digital input/output F2
state 0 or 1 RO Bit P
8.03 Digital input/output F3
state 0 or 1 RO Bit P
8.04 Digital input F4
state 0 or 1 RO Bit P
8.05 Digital input F5
state 0 or 1 RO Bit P
8.06 Digital input F6
state 0 or 1 RO Bit P
8.07 Terminal 30
state 0 or 1 RO Bit P
8.08 Status relay output
indicator 0 or 1 RO Bit P
8.09 Terminal 30 function
select 0 or 1 0 1 RW Bit
8.10 F1 destination or source parameter Pr 0.00 to Pr 20.50 Pr 10.06 Pr 10.03 RW Uni R P
8.11 F1
invert 0 or 1 0 RW Bit
8.12 F1 output
enable 0 or 1 1 RW Bit R
8.13 F2 destination or source parameter Pr 0.00 to Pr 20.50 Pr 10.33 RW Uni R P
8.14 F2
invert 0 or 1 0 RW Bit
8.15 F2 output
enable 0 or 1 0 RW Bit R
8.16 F3 destination or source parameter Pr 0.00 to Pr 20.50 Pr 6.31 RW Uni R P
8.17 F3
invert 0 or 1 0 RW Bit
8.18 F3 output
enable 0 or 1 0 RW Bit R
8.19 F4 destination parameter Pr 0.00 to Pr 20.50 Pr 6.30 RW Uni R P
8.20 F4
invert 0 or 1 0 RW Bit
8.21 F5 destination parameter Pr 0.00 to Pr 20.50 Pr 6.32 RW Uni R P
8.22 F5
invert 0 or 1 0 RW Bit
8.23 F6 destination parameter Pr 0.00 to Pr 20.50 Pr 1.41 RW Uni R P
8.24 F6
invert 0 or 1 0 RW Bit
8.25 Status relay source parameter Pr 0.00 to Pr 20.50 Pr 10.01 RW Uni R P
8.26 Status relay
invert 0 or 1 0 RW Bit
8.27 Positive logic
select 0 or 1 0 RW Bit R P
8.28 Open-collector outputs
select 0 or 1 0 RW Bit R P
RO Read Only parameter
Uni Unipolar variable parameter R Reset required for new value to take effect
Bi Bipolar variable parameter S New parameter-value saved at power-down
RW Read / Write parameter
Txt Text variable parameter P Protected; forbidden as destination parameter
Bit Bit parameter FLC Full-load current (max. continuous), Pr 11.32 {0.33}
