Parameter
Range(
Ú) Default(Ö)
Type
OL CL OL VT SV
12.01
Comparator 1 output indicator 0 or 1 RO Bit P
12.02 Comparator 2 output indicator 0 or 1 RO Bit P
12.03 Comparator 1 input source parameter Pr 0.00 to Pr 20.50 Pr 0.00 RW Uni P
12.04 Comparator 1 threshold level 0 to 100.0 % 0 RW Uni
12.05 Comparator 1 hysteresis 0 to 25.0 % 0 RW Uni
12.06 Comparator 1 output invert 0 or 1 0 RW Bit
12.07
Comparator 1 output destination
parameter
Pr
0.00 to Pr 20.50 Pr 0.00 RW Uni R P
12.13 Comparator 2 input source parameter Pr 0.00 to Pr 20.50 Pr 0.00 RW Uni P
12.14 Comparator 2 threshold level 0 to 100.0 % 0 RW Uni
12.15 Comparator 2 hysteresis 0 to 25.0 % 0 RW Uni
12.16 Comparator 2 output invert 0 or 1 0 RW Bit
12.17
Comparator 2 output destination
parameter
Pr
0.00 to Pr 20.50 Pr 0.00 RW Uni R P
RO Read Only parameter
Uni Unipolar variable parameter R Reset required for new value to take effect
Bi Bipolar variable parameter S New parameter-value saved at power-down
RW Read / Write parameter
Txt Text variable parameter P Protected; forbidden as destination parameter
Bit Bit parameter FLC Full-load current (max. continuous), Pr
11.32 {0.33}
