18 Unidrive User Guide
www.controltechniques.com Issue Number: 9
Figure 3-8 Through-panel mounting of model sizes 1 and 2
N
When drives are through-panel mounted, a baffle plate is required to
ensure the correct level of air-flow is maintained through the heatsink.
For further information, please refer to section 3.9 Baffle plates on
page 28.
Model
size 1
Model
size 2
B
ac
k
-p
l
ate
Back-plate
13.189in
14.331in
3.740in
7.874in
4.724in
3.150
in
11.614in 13.583in
0.512in
3.406in
0.650in
0.650in
13.189in
14.331in
7.480in
11.614in 13.583i
n
7.1
65
in
0.512in
NOTE
