4 Unidrive M100/M101/M200/M201/M300 Step By Step Guide
Issue Number: 1
STEP 5: Select cables and fuses or MCB
* These fuses are fast acting.
** For UL installations, the circuit breaker must be Listed under category control number DIVQ / DIVQ7, rated
600 Vac with a short circuit rating > 10 kA. In other countries, circuit breakers compliant with EN IEC 60947-2 are
recommended, with > 10 kA short circuit breaking capacity
The voltage rating of fuses and MCBs must be greater than or equal to the highest supply voltage of
the system. Fuses: The AC supply to the drive must be installed with suitable protection against
overload. Failure to observe this requirement will cause risk of fire.
Ground conductor size:- Either 10 mm
2
or two conductors of the same cross-sectional area as the input
conductors.
Model
Input
Phases
Fuses
MCB
rating**
Cables
IEC Class
gG
UL
Class CC
J, or T
*
IEC60364-5-52
mm
2
UL 508C
AWG
A A Input Output Input Output
01100017 1 10 15 15 1 1 16 16
01100024 1 16 15 15 1.5 1 14 16
02100042 1 20 20 15 2.5 1 12 16
02100056 1 25 25 15 4 1 10 16
01200017 1 6 6 15 1 1 16 16
01200024 1 6 6 15 1 1 16 16
01200033 1 10 15 15 1 1 16 16
01200042 1 16 15 15 1 1 16 16
02200024 1 / 3 6/6 6/6 15 1 1 16 16
02200033 1 / 3 10/10 10/10 15 1 1 16 16
02200042 1 / 3 16/10 15/10 15 1 1 16 16
02200056 1 / 3 20/16 20/15 15 2.5/1.5 1 12/14 16
02200075 1 / 3 20/16 20/15 15 2.5 1 12 16
03200100 1 / 3 25/20 25/20 25/20 4 1.5 10/12 14
04200133 1 / 3 25/20 25/20 25/20 4/2.5 2.5 10 12
04200176 3 25 25 25 4 2.5 10 12
02400013 3 6 6 15 1 1 16 16
02400018 3 6 6 15 1 1 16 16
02400023 3 6 6 15 1 1 16 16
02400032 3 6 6 15 1 1 16 16
02400041 3 10 6 15 1 1 16 16
03400056 3 10 15 15 1 1 14 16
03400073 3 16 15 15 1.5 1 12 16
03400094 3 16 15 25 2.5 1.5 12 14
04400135 3 20 20 20 2.5 2.5 10 12
04400170 3 25 25 25 4 2.5 10 12
The product is UL listed for use on a circuit up to 100 kA maximum supply symmetrical fault current,
when protected by fuses.
IEC cable sizes assume Copper conductor, PVC insulation, Installation method B2 and ambient
temperature of 40 °C (104 °F). UL cable sizes assume Copper conductor with insulation rated at 75 °C
(167 °F).
