CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
- 10 -
Indicator Lamps
The panel red (alarm) and amber (pre alarm) lamp indicators.
Active and Stored Engine ECU Codes
The panel also provides the ability to check the engine ECU for all ACTIVE and STORED engine ECU
codes. These codes can be viewed via the Active Codes and Stored Codes menus. In addition, the
control panel has its own Alarm Event Log menu that shows the last 16 engine ECU alarms as well as
any control panel specific alarms.
Engine
Fault/Shutdown
Lamp
