Configuration Menus
(1)
Input Configuration
Analog 1 Setup (Function, Message)
Digital Input 1 – Pre Set to Auto Start
(2)
Output Configuration
Relay Output 1 - Pre Set to Pre Alarm
Relay Output 2 - Pre Set to Fuel/Run
Relay Output 3 - Pre Set to Alarm
Relay Output 4 - Pre Set to Crank
(3)
Throttle Configuration
Throttle Type Selection (Default = TSC Vernier)
TSC Mode Selection (Default = Primary)
TSC Min Speed Selection (Default = 650 RPM)
TSC Max Speed Selection (Default = 2400 RPM)
TSC Bump Speed Selection (Default = 20 RPM)
TSC Ramp Rate Selection (Default = 100 RPM/Sec)
Throttle Curve Selection (Default = Linear)
Multistate Speed 1 Selection (Default = 650 RPM)
Multistate Speed 2 Selection (Default = 650 RPM)
Multistate Speed 3 Selection (Default = 650 RPM)
Multistate Speed 4 Selection (Default = 650 RPM)
