- 19 -
(4)
Engine Safety Configuration
Sender Check Bypass Time Period Selection (Default = 0:10)
Fuel Level Check Off/Always/Run (Default = Off)
Low Fuel Level Pre Alarm Selection (Default = 20%)
Low Fuel Level Alarm Selection (Default = 1%)
Fuel Level Alarm Time Delay Selection (Default = 0:05)
Oil Pressure Check Off/Always/Run (Default = Run)
Low Oil Pressure Pre Alarm Selection (Default = 6 PSI)
Low Oil Pressure Alarm Selection (Default = 5 PSI)
Oil Pressure Alarm Time Delay Selection (Default = 0:10)
Engine Temperature Check Off/Always/Run (Default = Run)
Low Temperature Pre Alarm Selection Deg. F (Default = 0F)
Low Temperature Alarm Selection Deg. F (Default = 0F)
High Temperature Pre Alarm Selection Deg. F (Default = 244F)
High Temperature Alarm Selection Deg. F (Default = 245F)
Engine Temperature Alarm Time Delay Selection (Default = 0:10)
Battery Volt Check Off/Always/Run (Default = Off)
Low Battery Volt Pre Alarm Selection (Default = 12.0 V)
High Battery Volt Pre Alarm Selection (Default = 15.0 V)
Battery Volt Trim Setting (Default = 5 100mV)
Over Speed Alarm Off/Always/Run (Default = Off)
Over Speed Alarm RPM Setting (Default = 3000 RPM)
Over Speed Alarm Time Delay Selection (Default = 0:05)
(5)
Module Configuration
Pressure & Temperature Units (Default = English)
Hour Meter Source (Default = Engine ECU)
Hour Meter Setting (Default = 0 Hours)
Display Battery Source (Default = J1939)
Pre Alarms Displayed (Default = 4)
Clear Operation Log Yes/No (Default = No)
Clear Alarm Log Yes/No (Default = No)
(6)
CAN Configuration
TSC1 Address (Default = 3)
Source Address (Default = 44)
Engine Address (Default = 0)
Oil/Fuel Transmit On/Off (Default = Off)
