Analog 1 Function Options
1) Fuel Level S-W – Fuel amount, in percentage, can be measured and displayed on the C3
module using a standard Stewart Warner scale sender of 240 ohms – 33 ohms. 240 = Empty
and 33 = Full. Sender ground must be common with battery negative.
2) Fuel Level VDO – Fuel amount, in percentage can be measured and displayed on the C3
module using a VDO scale sender of 10 ohms – 180 ohms. 10 = Empty and 180 = Full.
Sender ground must be common with battery negative.
3) Oil Pressure SW 100 PSI – Oil pressure, in PSI, can be measured and displayed on the C3
module using a standard Stewart Warner scale sender of 240 ohms – 33 ohms. 240 = 0 PSI
and 33 = 100 PSI. Sender ground must be common with battery negative.
4) Oil Pressure SW 125 PSI – Oil pressure, in PSI, can be measured and displayed on the C3
module using a standard Stewart Warner scale sender of 240 ohms – 33 ohms. 240 = 0 PSI
and 33 = 125 PSI. Sender ground must be common with battery negative.
5) Oil Pressure SW bar – Oil pressure, in bar, can be measured and displayed on the C3 module
using a standard Stewart Warner scale sender of 240 ohms – 33 ohms. 240 = 0 bar and 33 =
7 bar. Sender ground must be common with battery negative.
6) Oil Pressure VDO PSI – Oil pressure, in PSI, can be measured and displayed on the C3 module
using a standard VDO scale sender of 10 ohms – 180 ohms. 10 = 0 PSI and 180 = 150 PSI.
Sender ground must be common with battery negative.
7) Oil Pressure VDO bar – Oil pressure, in bar, can be measured and displayed on the C3 module
using a standard VDO scale sender of 10 ohms – 180 ohms. 10 = 0 bar and 180 = 7 bar.
Sender ground must be common with battery negative.
8) Switch – This setting allows for a switch to be connected rather than an analog sender. Set
Analog 1 Message to assign a label to the switch device.
9) None – Set to None when no functionality is required.
