CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
- 4 -
PRIMARY CONNECTOR (14 Pin)
Pin
Function
Pin
Function
1
Fuel Solenoid
8
N/A
2
Switched Battery to Horn
9
Battery Positive
3
Battery Positive
10
Key Auto Detect
4
Auto Crank Signal
11
Switched Power to C3M
5
Preheat Signal
12
Battery Negative
6
Battery Positive
13
Fuel Level Sender Input
7
N/A
14
Remote Start Input
SECONDARY CONNECTOR (23 Pin)
Pin
Function
Pin
Function
Pin
Function
1
9
16
2
Oil Pressure Sender Input
10
Engine Temp Sender Input
17
Low Float Input
3
11
18
4
12
19
5
MPU+ or Tach Input
13
20
6
14
21
7
15
22
8
23
CAUTION:
Maximum current draw for signal circuits is 5 amps
CAUTION:
Maximum current draw relay output circuits is 5 amps
