CONTROLS, INCORPORATED

C O N T R O L S Y S T E M S & S O L U T I O N S

- 5 -

PANEL CONNECTORS

Engine Harness Connector –Deutsch 16 pin (HDP24-24-21PE)

16 Pin Engine Harness Connector

Function

Battery Positive

Battery Negative

Key On Power (Fuel/Run Signal)

Preheat Signal

Crank Signal

Oil Pressure Sender Input

Engine Temperature Sender Input

MPU-

MPU+ or Tach Input

Alternator Excite

Ground

Fuel %

CAUTION:

Maximum current draw for relay

output circuits is 5 amps
