CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
- 13 -
CONTROL PANEL RELAY OUTPUTS
The panel provides relay outputs defined below located in the Output Configuration menu. The
relays are rated at 5 amps.
The panel is shipped from the factory with the highlighted outputs enabled and pre-
wired in the panel.
Relay
Heading
Default
Connector
Pin
Relay 1
Ground output
only
Function
Pre-Alarm
Polarity
Positive
Initial State
Off
Relay 2
Function
Fuel/Run
21 Pin
Connector
G
Polarity
Positive
Initial State
On
Relay 3
Function
Alarm
Polarity
Positive
Initial State
Off
Relay 4
Function
Crank
21 Pin
Connector
D
Polarity
Positive
Initial State
Off
Relays 5-8 Available
RELAY FUNCTIONS
Available relays can be assigned for different uses.
a. None - Assign to “none” when not used.
b. Pre Alarm - Relay will be active when there is a pre alarm condition. Typically used to
drive an alarm horn or lamp. Also can be used to send a signal to a monitoring
station.
c. Alarm - Relay will be active when there is an alarm condition. Typically used to drive
an alarm horn or lamp. Also can be used to send a signal to a monitoring station.
d. Pre Alarm & Alarm - Energizes an external audible alarm when a pre alarm or alarm
condition is present. Pressing the ENTER button will silence.
e. Alarm Horn - Energizes an external audible alarm when an alarm condition is present.
Pressing the ENTER button will silence.
