Indicator Lamps
The panel has six lamp indicators.
Active and Stored Engine ECU Codes
The panel also provides the ability to check the engine ECU for all ACTIVE and STORED engine ECU
codes. These codes can be viewed via the Active Codes and Stored Codes menus. In addition, the
control panel has its own Alarm Event Log menu that shows the last 16 engine ECU alarms as well as
any control panel specific alarms.
Engine
Fault
Lamp
Regen
Inhibit
Lamp
Regen
Active
Lamp
Engine
Alarm
Lamp
DPF
Lamp
DEF
Alert
Lamp
