Convaid Carrot 3 - Chest Support and Harness; Chest Support Pad Adjustment

22
Chest Support Pad Adjustment
To raise the height of the Chest Support Pad, press & hold
the Height Adjustment Lever (Yellow) on the front of the
child seat, and pull on the pad (Fig. A). To lower the chest
support pad, pull the chest support strap (Fig. B).
!!
WARNING!
The top of the Chest Support Pad must
be at armpit level or lower. Positioning the
support pad too high may cause choking
Harness Buckle - Fasten / Release
1. Fasten: Hold the harness buckle with one hand.
Use the other hand to insert buckle clasps into
the harness buckle (Fig. C). Proper connection is
conrmed when you hear an audible click after
inserting each buckle clasp.
2. Release: Hold the harness buckle with one hand.
With the other hand, press the release button and
remove both clasps from the buckle (Fig. D).
Chest
Support
Height
Lever
(Yellow)
Fig. A
Fig. B
Fig. C
Fig. D
Chest Support
