24
IMPORTANT:
• Height of the shoulder harness strap moves with the
height of the backrest.
• The Shoulder Harness Strap must be at or above the
child’s shoulders, and parallel to the ground. (Fig A)
• The Shoulder Harness Strap is for positioning only,
and not designed to support occupant in a crash.
Fig. B Backrest Extensions
snaps into place by
pushing.
Backrest
Fig. A
Backrest Height Adjustment
The height of the backrest can be adjusted an additional
4" as the child grows.
To adjust: Pull and hold the black “D” shaped ring at
the top of the backrest to release lock. (Fig. D) While
pulling the release lever, move backrest to desired height
and release ring. To fully engage the lock, slightly move
backrest until it “clicks” into place.
Note: After adjusting the height of the backrest to a
more extended position, the harness belt may need to
lengthened. Please refer to instructions for Harness Belt
Length Adjustment on bottom of page 19 .
Fig. D
Backrest Extensions - 2" or 4" (OPTIONAL ACCESSORY)
Backrest Extensions are designed to ll the space
exposed between the backrest and the seat when you
extend the backrest. (Fig. B)
To add an extension, snap the Backrest Extension(s)
onto exposed rods. (Fig. C)
Fig. C
