26
Rodded Seat Extension - Long 7"
Allows the legs to be stretched out and comfortably
supported.
Allows the knees to be bent, with the femurs comfortably
supported.
Rodded Seat Extensions (OPTIONAL ACCESSORY)
Rodded Seat Extension - Short 2"
Seat
Seat Extensions (OPTIONAL ACCESSORY)
Seat Extensions are designed to ll the space
around the metal rods created when you use a
rodded seat extension and/or extend the footrest.
(Fig. C and D)
Fig. C Seat Extension snaps into
place when used with the Rodded
Seat Extension
Seat Depth Release Lever
Fig. D Seat Extension snaps into
place when used with the with
Footrests
Fig. BFig. A
Installing Rodded Seat Extensions
Release lock by pulling the black “D” shaped ring - Seat Depth Release Lever on
the front of the Carrot 3, and while pulling the lever (Fig. A), insert and adjust the
position of the rodded seat extension. (Fig. B)
