32
!!
WARNING!
The Vehicle’s lap shoulder (3 point) safety belt MUST BE USED in
addition to the harness straps (5 point) of the Carrot 3.
DO NOT secure a child only with the harness straps (5-point) of
the Carrot 3; ALWAYS use the vehicle’s lap shoulder (3-point)
safety belt at the same time to secure the Carrot 3 and the child.
Not using vehicle’s lap shoulder (3-point) safety belt could cause
your child restraint to not perform as intended, and increase the
potential of serious injury or death.
Figure A. below illustrates a vehicle lap and shoulder (3-point
safety) belt secured over the Carrot 3. The Carrot 3 is shown at
its smallest and largest congurations.
IMPORTANT: Upper belt path should be above occupant’s
shoulder for proper securement.
Securing Your Child
Fig. A
