Kyle Form 4C Microprocessor-Based Recloser Control Programming Guide
Sequence Position
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
38 -- 0 NO -- -- -- Sequence Position --
• Sequence position is used to verify proper sequenc-
ing of the control.
• Displays a readout of the control position in the oper-
ations-to-lockout sequence.
• Accessible from the keyboard with the SELECT
LOWER FUNCTION and SEQUENCE POSITION
key.
Targets
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
30 Reset 0 0 NO -- -- -- Examine Targets --
32 Reset 0 0 NO -- -- -- Examine Target Counter - Ground --
33 Reset 0 0 NO -- -- -- Examine Target Counter - Phase 1-2 --
34 Reset 0 0 NO -- -- -- Examine Target Counter - Phase 3-4 --
35 Reset 0 0 NO -- -- -- Examine Target Counter - Phase 5-6 --
36 Reset 0 0 NO -- -- -- Examine Target Counter - Sensitive --
Ground/Earth Fault
• Targets indicate which phase(s)/ground was above
minimum trip when tripping occurred.
• Press the TARGET key to display the faulted
phase(s)/ground.
• Pressing the TARGET COUNTER key the first
time displays the cumulative number of ground
trip operations. Continuous scrolling with the
TARGET COUNTER key advances the display to
show the cumulative number of trip operations for
each phase and Sensitive Ground/Earth Fault.
• When the Sensitive Ground/Earth Fault feature is
ON, the Target Display is altered to distinguish
between sensitive ground/earth fault trips and nor-
mal ground fault trips. The ground fault portions of
the display shows an E for sensitive earth fault oper-
ation and G for normal ground fault operation.
• Reset with CLEAR key.
Features ON/OFF (cont’d)
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
26 1 0 YES -- -- -- Supervisory Via Momentary Contact OFF
(ON/OFF)
• With feature ON, supervisory operation is provided
with a momentary-pulse contact instead of a main-
tained contact. If maintained contacts are used with
the feature ON, the maintained contacts must be
pulsed to obtain the appropriate supervisory function.
• Select Supervisory Via Momentary Contact ON/OFF
using the CHANGE key.
• For Loop Scheme (LS) applications (CPU Firmware
Version 14.XX), the Supervisory via Momentary
Contact cannot be changed.
