Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
44 -- 0 NO -- -- -- Demand Current- Ground (A) --
45 -- 0 NO -- -- -- Demand Current- Phase 1-2 --
46 -- 0 NO -- -- -- Demand Current- Phase 3-4 --
47 -- 0 NO -- -- -- Demand Current- Phase 5-6 --
• Indicates the demand currents for all phases and
ground.
Metering
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
40 -- 0 NO -- -- -- Instantaneous Current - Ground (A) --
41 -- 0 NO -- -- -- Instantaneous Current - Phase 1-2 --
42 -- 0 NO -- -- -- Instantaneous Current - Phase 3-4 --
43 -- 0 NO -- -- -- Instantaneous Current - Phase 5-6 --
• Indicates the instantaneous line currents for all
phases and ground.
• After interrogating any of these four access codes,
use the CURRENT METERING key to scroll to the
other current parameters.
Using standard sensing current transformers mounted
within Kyle electronically controlled reclosers, current
metering data is shown on the control panel LCD dis-
play, eliminating the need for separate meters and
bushing current transformers.
Current metering in the Form 4C control monitors (in
rms A):
• Instantaneous current values.
• Phase demand current values integrated over a
programmable time interval of 5 or 15 minutes.
• Ground demand current values integrated over a
programmable time interval of 1 or 5 minutes.
• Maximum demand current (drag-hand function) val-
ues for phase and ground.
Operations Counter
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
39 Reset 2 0 NO -- -- -- Operations Counter --
• This key displays the total number of control trip
operations.
• Accessible from the keyboard with OPERATIONS
COUNTER key.
• Reset with CLEAR key.
• Control trip operations are initiated via manual oper-
ation of the pistol-grip switch on the front panel or
through automatic or supervisory operation.
