Kyle Form 4C Microprocessor-Based Recloser Control Programming Guide
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
64 -- 0 NO -- -- -- Switch Mode Status --
• Applicable to controls with CPU Firmware 8.XX,
11.XX, and 12.XX only.
• Indicates the ON or OFF status of the Switch Mode
feature. When the front panel switch is in the
RECLOSER MODE position, the switch mode is OFF.
• Switch Mode is selected by the front panel
RECLOSER MODE/SWITCH MODE switch or from
supervisory control.
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
63 -- 0 NO -- -- -- Hot Line Tag (HLT) Status --
• Applicable to controls with CPU Firmware versions
8.XX, 9.XX, and 10.XX only.
• Indicates ON or OFF status of Hot Line Tag.
• Hot Line Tag is selected either by the front panel
HOT LINE TAG switch or from supervisory control.
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
57 1 0 NO 15 5 -- Select Integration Interval - Phase 5
(5 or 15 minutes)
57 1 0 NO 5 1 -- Select Integration Interval - Ground 1
(1 or 5 minutes)
• Changes integration time value of demand metering.
• Use PHASE/GROUND key to select phase or
ground integration intervals.
• Select Integration Interval using the CHANGE key.
Metering (cont’d)
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
48 Reset 0 0 NO -- -- -- Maximum Demand Current - Gnd (A) --
49 Reset 0 0 NO -- -- -- Maximum Demand Current - Phase 1-2 --
50 Reset 0 0 NO -- -- -- Maximum Demand Current - Phase 3-4 --
51 Reset 0 0 NO -- -- -- Maximum Demand Current - Phase 5-6 --
• Indicates the maximum demand current for all phases
and ground.
• Reset with CLEAR key.
Status Codes
