Kyle Form 4C Microprocessor-Based Recloser Control Programming Guide
Malfunction Code
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
66 Reset 0 0 NO -- -- -- Malfunction Status --
1 - Failure to close from a supervisory
signal
2 - Low or high battery voltage
3 - Power down in less than 48 hours on
battery power
4 - Failed to close from the manual con-
trol switch
5 - Internal diagnostic alarm
• Identifies the specific malfunction as indicated by the
Malfunction LCD indicator on the control panel.
• Reset with CLEAR key.
TCC Group
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
70 1 0 NO 4 1 1 TCC Group 1
• Selects any one of four time–current-curve groups.
• TCC’s in only one timing group are available for
programming at a time.
• Select TCC group using the CHANGE key.
• Display will shut off after a TCC group change.
The table below lists the TCC’s for the Form 4C con-
trol and provides a cross-reference to the Form 3A
control equivalents. The curves are arranged in four
keyboard-accessible timing groups. Each timing
group contains a selection of 21 TCC’s.
Curves 200, 201, and 202 in timing group 4 match IEC
curves normally described as inverse, very inverse,
and extremely inverse, respectively. Time–current
curves can also be selected and programmed via the
data port or remotely through the digital communica-
tions accessory.
Form 4C Form 3A
Timing Group† Time–Current Curves
Ground Phase
1 2 3 4 MEA216 MEA217
101 101 101 101 A
102 102 102 102 1
111 111 111 111 8*
135 135 135 135 2
105 105 105 105 R
117 117 117 117 B
133 133 133 133 C
140 140 140 140 3
116 116 116 116 D
132 132 132 132 E
104 104 104 104 N
142 13
162 K
165 K
106 106 106 106 4
141 141 11
131 131 9
114 114 5
136 136 6
119 119 14
Form 4C Form 3A
Timing Group† Time–Current Curves
Ground Phase
1 2 3 4 MEA216 MEA217
138 138 138 W
164 J
118 M
113 8
161 T
152 7
163 F
112 15
107 L
103 17
115 P
121 G
122 H
151 18
139 16
137 V
134 Z
120 Y
200
201
202
† All curves in groups are interchangeable for phase and ground.
TABLE 5
Time–Current Curve Groups
