Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
76 2 0 NO 9999 0 -- Control Identification Number #
# Factory setting is the last four digits of the control
serial number.
• If the identification number is changed, a record must
be kept of the original serial number of the control. The
serial number is required for any authorized service
or repair work. The complete serial number appears
on the nameplate located on the control cabinet.
Firmware Version / Control Identification
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
72 -- 0 NO -- -- -- CPU Firmware Version Y.XX*
* Y represents the version of the CPU firmware:
.XX represents the protocol used.
EXAMPLE:
Y.14 represents CPU firmware with Protocol 2200.
Y.15 represents CPU firmware with Protocol 2179.
8.XX includes Hot Line Tag (HLT) and Switch Mode
9.XX includes HLT and Sensitive Ground Fault (SGF)
10.XX includes HLT and Trip on TCC2 (TCC2)
11.XX includes Switch Mode and TCC2
12.XX includes Switch Mode and SGF
13.XX includes SGF and TCC2
14.XX Form 4C/LS Control
15.XX Standard Form 4C
IMPORTANT: The version number suffix of the
CPU and the Display firmware (Access Code 78)
must be identical.
Line Frequency
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
71 3 0 NO 60 50 -- Line Frequency 60
• Change the operating frequency from 50 to 60 Hz • Select Line Frequency (50/60) using the CHANGE
key.
Firmware Version
