Kyle Form 4C Microprocessor-Based Recloser Control Programming Guide
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
78 -- 0 NO -- -- -- Display Board Firmware Version Z.XX
• Z represents the latest version of the display board.
.XX represents the protocol used.
EXAMPLE:
Z.14 represents display board firmware with Proto-
col 2200.
Z.15 represents display board firmware with Proto-
col 2179.
IMPORTANT: The version number suffix of the
CPU (Access Code 72) and the Display firmware
must be identical.
Firmware Version / Control Identification (cont’d)
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
77 -- 0 NO -- -- -- CPU Firmware Revision Number --
• Identifies the CPU firmware revision programmed
into the control.
